Cascone Castone CTA-1000p vocal amplifier

Description

huendeskes
FOR SALE!!!



The CTA series is a 60W output mixer amplifier with three microphone and two line inputs, shared bass and treble tone controls, and per-channel volume control. It can be used for 100V sound systems or 4-16 Ohm loads. The following features justify the wide applicability of these devices for information and entertainment sound reinforcement tasks in institutions, stores, outdoor events, etc. Main features:



two line inputs AUX1, AUX2 (RCA connector for background music, programs, etc.)

three microphone inputs MIC1, MIC2, MIC3 (6.3 JACK connectors)

The MIC1 input signal automatically mutes or attenuates the MIC2, MIC3, and AUX1, AUX2 input signals. The mute level can be adjusted with a potentiometer on the back in the range of 0-30dB (MUTE)

line output on RCA connectors (for recording, another amplifier, etc.)

speakers, sound systems can be connected to the ground-independent, transformer output (4-16 Ohm, 70V, 100V) with screw terminals

230V mains power supply

On the front panel, you will find the MIC1 input, independent volume control for each channel, shared bass and treble tone controls, and an output signal level meter consisting of 5 LEDs, as well as a fault indicator LED (PROTECT)

the device has an effective protection system (short circuit, overload) which indicates abnormal operating conditions with the PROTECT LED and sound

the device is fan-cooled
